TMC/3 - Multiple Automatic Mosaic, Strip, Tile Cutting Machine with 3 Heads
FOB Price:
Type:
Stone Factory MachinesStone Finishing, Profiling MachinesMosaic Cutting Machine
Usage:
Granite, Marble, Limestone, Slate, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Warranty:12 Months
Install and Guarantee:Customer pay for installation, Remote guidance installation
Maintenance:Remote troubleshooting
Machinery Function Features
PATENTED
Automatic machine for cuts, antislip incisions, pre-cut and special cut such as: mosaic, triangle, rombhus. Able to work with marble, granite, gres porcellanato, agglomerated, brick and single-double firing.
ADVANTAGES OF TMC3 SYSTEM
- On the shaft of motor-spindle it is possible to mount till 4 cutting blades, divided by spacers and flanges, in order to obtain different sizes and multiple cuts contemporarly.
- The motorized conveyor belt improves the working quality and allows the production of pieces continuously.
- The guide positioned on motor side and the pressor bar guarantee, during working phase, a strong stability and an high level of finishing piece.
- All adjustments are facilitated by the use of handwheels and they do not require the use of tools.
- A lateral roller allows to lay the big sizes to be worked
- TMC3 has more speed of material progress and it allows to make pre-cut, bevel and cut.
Automatic machine for cuts, antislip incisions, pre-cut and special cut such as: mosaic, triangle, rombhus. Able to work with marble, granite, gres porcellanato, agglomerated, brick and single-double firing.
ADVANTAGES OF TMC3 SYSTEM
- On the shaft of motor-spindle it is possible to mount till 4 cutting blades, divided by spacers and flanges, in order to obtain different sizes and multiple cuts contemporarly.
- The motorized conveyor belt improves the working quality and allows the production of pieces continuously.
- The guide positioned on motor side and the pressor bar guarantee, during working phase, a strong stability and an high level of finishing piece.
- All adjustments are facilitated by the use of handwheels and they do not require the use of tools.
- A lateral roller allows to lay the big sizes to be worked
- TMC3 has more speed of material progress and it allows to make pre-cut, bevel and cut.
Technical Data
Parameters |
Unit |
TMC/3 |
Spindle power |
kw |
5.8 |
Machine overall length |
mm |
2980 |
Approx. Weight |
Kg |
510 |
Machine overall height |
mm |
1500 |
Min. cutting size |
mm |
25 |
Water pump |
lt |
200 |
Lifting motor power |
kw |
0.25 |
Max. cutting width |
mm |
330 |
No. of cutting discs |
nr |
4 + 4 + 4 |
Cutting motor speed rpm |
rpm |
2800 |
Machine overall width |
mm |
1260 |
Voltage |
V/Hz |
400 V 50Hz |
Water pump power |
kw |
1x0,37 |
Max. working thickness |
mm |
40 |
Conveyor belt width |
mm |
350 |
Diameter of cutting discs |
mm |
300 |
