Construction Site Saw MANTA INOX 120- Mitre Saw
FOB Price:€2995-2995
Type:
Stone Factory MachinesStone Tile Cutting MachinesMitre Saw, Edge Cutting Machine
Usage:
Granite, Marble, Limestone, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Warranty:12 Months
Install and Guarantee:Remote guidance installation
Maintenance:Remote troubleshooting
Machinery Function Features
Construction site saw MANTA INOX 120
€ 2,995.00 *
excl. VAT plus shipping costs
Available again soon
Product number: O16.102
description
Product information "construction site saw MANTA INOX 120"
Special edition
for cutting tiles, natural stone, cast stone slabs and other building materials
latest generation of mobile stone saw with powerful motor, stainless steel tub, mini battery laser and stop
very robust and durable construction
full-surface support table for thin workpieces
precise cuts thanks to the 40 mm diameter precision round guide with recirculating ball bearings
more stability thanks to machine feet with cross bracing
Easily transportable thanks to the folding machine feet and transport wheels (with a cutting length of 1500mm, rigid feet)
maximum cutting depth 110 mm | Speed 2,800 rpm | max. ø diamond cutting discs 350 mm | Bore 25.4 mm, power 2.6 kW with motor brake / 230 V | Galvanized swivel element, infinitely adjustable 45-90 degrees | Height adjustment via M24 threaded rod with large handwheel
Dimensions (L / W / H): 1,770 x 660 x 770 mm
Weight: 120 kg
Cutting length: 1,250 mm
Cutting depth: 60/80/110 mm
Cutting disc ø: 250/300/350 mm
€ 2,995.00 *
excl. VAT plus shipping costs
Available again soon
Product number: O16.102
description
Product information "construction site saw MANTA INOX 120"
Special edition
for cutting tiles, natural stone, cast stone slabs and other building materials
latest generation of mobile stone saw with powerful motor, stainless steel tub, mini battery laser and stop
very robust and durable construction
full-surface support table for thin workpieces
precise cuts thanks to the 40 mm diameter precision round guide with recirculating ball bearings
more stability thanks to machine feet with cross bracing
Easily transportable thanks to the folding machine feet and transport wheels (with a cutting length of 1500mm, rigid feet)
maximum cutting depth 110 mm | Speed 2,800 rpm | max. ø diamond cutting discs 350 mm | Bore 25.4 mm, power 2.6 kW with motor brake / 230 V | Galvanized swivel element, infinitely adjustable 45-90 degrees | Height adjustment via M24 threaded rod with large handwheel
Dimensions (L / W / H): 1,770 x 660 x 770 mm
Weight: 120 kg
Cutting length: 1,250 mm
Cutting depth: 60/80/110 mm
Cutting disc ø: 250/300/350 mm
Technical Data
Parameters |
Unit |
MANTA INOX 120 |
Max. cutting spindle tilting angle |
° |
45-90 |
Main motor rotation speed |
r/min |
2800 |
Approximate weight |
Kg |
120 |
Machine length (L) |
mm |
1770 |
Machine height (H) |
mm |
770 |
Diamond blade diameter |
mm |
250/300/350 |
Main motor power |
kw |
2.6 |
Max. cutting length |
mm |
1250 |
Standard voltage |
V |
230 |
Machine width (W) |
mm |
660 |
Blade bore size |
mm |
25.4 |
Max stone thickness |
mm |
60 / 80 / 110 |
